Debevec and Jitendra Malik at ) or data rendered in LightWave saved in one of the high dynamic range formats.
Lightwave 3d plugins series#
This can be imagery generated from a series of photographs taken at various exposures and composited (see Recovering High Dynamic Range Radiance Maps from Photographs by Paul E. LightWave can utilise high dynamic range detail, as it is generated internally (e.g., in the case of a very bright light) or from data in image files. This may not seem significant at first glance - white is white after all - but, if we look at how LightWave utilizes that data, it becomes very exciting.
This means that when LightWave points a light at a surface, while the final rendered pixel may reach only RGB 255, 255, 255 for pure white, internally that pixel may have reached ten times that amount. LightWave, however, calculates all internal data without limits and with IEEE floating-point accuracy.
All of these effects can be seen in images captured by devices that do not support high dynamic ranges.īecause computer graphics applications were designed to output to devices that would not understand pixel values above RGB 255, 255, 255, most applications do not provide for any value to exceed these limits. For example, sunlight streaming into a room will bounce off the floor and add a subtle illumination to the walls and ceiling that would otherwise be left dark ( this bouncing of light is known as radiosity). These very bright surfaces can also contribute to the overall lighting of a scene. Some of those artifacts can be seen as blooming areas of brightness, color bleed, luminance spill, lens streaking, and many other visual cues that tell the viewer there is a very bright light source in the scene. When exposed to high dynamic range visuals, such as a sunset or a desert landscape, the lens of a camera will produce some level of artifacting. Video cameras, however, are limited to a fixed range that fits closely to the same 256-step limit. Film can also react to a much wider range. In the real world, the human eye can perceive a much higher range of brightness and color values. See the discussion on radiosity for additional information on high dynamic range images. This means the maximum amount of color or luminance variation an image is allowed is merely 256 steps. Those 256 steps of color represent eight bits and together all three channels make up a 24-bit image. These values typically range from 0 to 255. In computer graphics, color is displayed as a triplet value: red, green and blue. 512 x 512 eight-bit color-mapped image:.Here are some examples dealing with a 512 x 512 image in various formats, and how much memory is used for the base image and the first couple mipmaps: Floating-point images use 96 bits per pixel and have 96-bit mipmaps. For color images, their mipmaps, however, are 24-bit since they must include colors in between color palette entries. Eight-bit grayscale and eight-bit index-color images remain in eight-bit form internally. However, because the mipmaps are pre-processed and loaded into memory, they can be used immediately for textures instead of continually shrinking down the base image this saves rendering time, but requires more memory. As textures move farther away from the camera, they obviously must be scaled down. Each pre-processed image is a power of two smaller than the previous level. Mipmapping is a process where a series of images with progressively lower resolutions are created from a base (full-resolution) image. Supported Web 3D: QuickTimeVR, VRML and Shockwave for export. Supported animation formats: AVI (any installed codec), QuickTime, QuickTime Stereo, Flexible Image Format, Storyboard, 4X Storyboard, Film Expand. Supported image formats include but are not limited to: PSD, Alias, BMP, Cineon FP, DPX, Flexible Image Format, IFF, JPEG, PCX, PICT, PNG, Radiance, RLA, RPF, SGI, Sun, TIFF, Targa, VBP, and YUV image formats. If you have any of these images using the. The filename extension for Radiance images is. However, when you save alpha images directly, you save only the alpha image, even if the format is 32-bit. When a 32-bit format is selected for saved RGB images, the 8-bit Alpha image is stored along with the 24-bit RGB data.
